Product Summary
The JQX-115F is a miniature high power relay.
Parametrics
JQX-115F absolute maximum ratings: (1)Max. switching voltage: 440VAC; (2)Max. switching current: 16A; (3)Max. switching power: 2000VA; (4)Initial Contact Resistance Max: 50Ω; (5)Coil power: 0.4W.
Features
JQX-115F features: (1)Low height 15.7 mm; (2)16A switching capabilities; (3)1&2 pole configurations; (4)5KV dielectric coil to contacts; (5)Creepage distance 10mm; (6)Sealed & unsealed type available.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 JQX-115F |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
JQX-115F-I |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
JQX-115F-T |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
JQX-115F-TH |
Other |
|
Data Sheet |
Negotiable |
|
||||
