Product Summary
The A2982SLWTR-T is an 8-channel source driver. It is useful for interfacing between low-level logic and high-current loads. Typical loads include relays, solenoids, lamps, stepper and/or servo motors, print hammers, and LEDs. The A2982SLWTR-T indicates an 18-lead plastic dual in-line package with copper lead frame for optimum power dissipation. Under normal operating conditions, the device will sustain 120 mA continuously for each of the eight outputs at an ambient temperature of +50℃ and a supply of 15 V.
Parametrics
A2982SLWTR-T absolute maximum ratings: (1)Output Voltage Range, VCE: 5 V to 50 V; (2)Input Voltage, VIN: 20 V; (3)Output Current, IOUT: -500 mA; (4)Operating Temperature Range, TA: -20℃ to +85℃; (5)Storage Temperature Range, TS: -55℃ to +150℃.
Features
A2982SLWTR-T features: (1)TTL, DTL, PMOS, or CMOS Compatible Inputs; (2)500 mA Output Source Current Capability; (3)Transient-Protected Outputs; (4)Output Breakdown Voltage to 50 V; (5)DIP or SOIC Packaging.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 A2982SLWTR-T |
|
IC SOURCE DRIVER 8CHAN 20-SOIC |
Data Sheet |
|
|
||||||||||||||||||
