Product Summary
The AT49LV040T-90TI is a 3-volt-only, 4-megabit Flash memory organized as 524,288 words of 8-bits each. Manufactured with the advanced nonvolatile CMOS technology of Atmel, the device offers access times to 120 ns with power dissipation of just 90 mW over the commercial temperature range. When the AT49LV040T-90TI is deselected, the CMOS standby current is less than 50 mA. The device contains a user-enabled boot block protection feature. To allow for simple in-system reprogrammability, the AT49LV040T-90TI does not require high input voltages for programming. Three-volt-only commands determine the read and programming operation of the device.
Parametrics
AT49LV040T-90TI absolute maximum ratings: (1)Temperature Under Bias: -55℃ to +125℃; (2)Storage Temperature: -65℃ to +150℃; (3)All Input Voltages(including NC Pins)with Respect to Ground: -0.6V to +6.25V; (4)All Output Voltages with Respect to Ground: -0.6V to VCC + 0.6V; (5)Voltage on OE with Respect to Ground: -0.6V to + 13.5V.
Features
AT49LV040T-90TI features: (1)Single Voltage for Read and Write: 2.7V to 3.6V (BV), 3.0V to 3.6V (LV); (2)Fast Read Access Time - 120 ns; (3)Internal Program Control and Timer; (4)16K bytes Boot Block With Lockout; (5)Fast Chip Erase Cycle Time - 10 seconds; (6)Byte-by-Byte Programming - 30 μs/Byte Typical; (7)Hardware Data Protection; (8)DATA Polling For End Of Program Detection; (9)Low Power Dissipation: 25 mA Active Current; 50 μA CMOS Standby Current; (10)Typical 10,000 Write Cycles; (11)Small Packaging: 8 × 8 mm CBGA; 8 × 14 mm V-TSOP.
Diagrams
